Bucket Elevators
Improve your Processing Operation with
Bucket Elevators From Wilkey Industries
Wilkey Industries designs and fabricates standard and high capacity bucket elevators to meet your processing needs.
Features include:
- Bucket sizes range from 7” x 5” to 24” x 7”
- Crowned and vulcanized pulleys
- Nu-Hy Steel Buckets Standard (plastic available)
- Two-piece hood for accessibility
- Bearing plates with vertical adjustment bolts for final installation alignment
- Fully adjustable throat plate
- Heavy duty 10 gauge steel construction on high capacity model boots
- Optional service platforms and ladders for easy maintenance
- Quality motors and gearboxes for excellent service and longevity
- Models ranging from 12 to 53 tons per hour @ 20 lbs/cu ft
Our excellent customer service, skilled installers, and the ability to provide interface to the equipment, make us a leader in bucket elevator fabrication and installation.
Call today and see how we can improve your processing operation!
- Bucket Elevators; Rack Card [3.93 MB PDF]
Bucket Elevator Size Chart:
| SIZE | MODEL | INLET HT (IN) |
INLET L/W (IN x IN) |
BELT SPEED (FPM) |
BUCKET SIZE |
BUCKET SPACING CL (IN) |
UNIT CAPACITY (FT3/HR) |
|---|---|---|---|---|---|---|---|
| 12 | E 1205 | 32 | 10 X 8 | 198 | 9 X 5 | 9 | 1184 |
| 12 | E 1206 | 32 | 10 X 8 | 198 | 9 X 6 | 9 | 1694 |
| 14 | E 1405 | 32 | 10 X 10 | 198 | 11 x 5 | 9 | 1447 |
| 14 | E 1406 | 32 | 10 X 10 | 198 | 11 x 6 | 9 | 2076 |
| 17 | E 1705 | 44 | 16 x 13 | 197 | 14 x 5 | 9 | 1832 |
| 17 | E 1706 | 44 | 16 x 13 | 197 | 14 x 6 | 9 | 2632 |
| 17 | E 1707 | 44 | 16 x 13 | 197 | 14 x 7 | 9 | 3664 |
| 20 | E 2005 | 44 | 16 X 15 | 197 | 16 X 5 | 9 | 2094 |
| 20 | E 2006 | 44 | 16 X 15 | 197 | 16 X 6 | 9 | 3005 |
| 20 | E 2007 | 44 | 16 X 15 | 197 | 16 X 7 | 9 | 4185 |
| 24 | E 2406 | 44 | 16 X 19 | 197 | 20 x 6 | 9 | 3760 |
| 24 | E 2407 | 44 | 16 X 19 | 197 | 20 x 7 | 9 | 5241 |
